Excitation
5 to 10 VDC recommended, 12 VDC or VAC max.
Output
2 to 4 mV/V, nominal, depending on model
Linearity
≤0.15% of full scale measuring range, depending on model
Temperature Range
Standard (-ST) is -40 °C to +1000 °C (-40 °F to 1832°F)
Cable
Integral, ultra-flexible cable, 2.5 m (8 ft) standard
Coolant Interface
Two barbed hose fittings for 1/8” (3.2 mm) ID coolant hoses
Specimen Size
Works with sample diameters from 4.5 to 16 mm (0.18 to 0.63 inch)
Contact Force
Adjustable, 100 to 300 g typical
