Excitation
5 to 10 VDC recommended, 12 VDC or VAC max.
Output
2 to 4 mV/V, nominal, depending on model
Accuracy
Standard configurations meet ASTM E83 class B-1 and ISO 9513 class 0,5 requirements for accuracy. A test certificate is included.
Linearity
≤0.15% of full scale measuring range, depending on model
Temperature Range
Standard (-ST) is -40 °C to +100 °C (-40 °F to 210 °F)
Cable
Integral, ultra-flexible cable, 2.5 m (8 ft) standard
Specimen Size
Works with samples 0.25 to 25 mm (0.01 to 1.0 inch) width or diameter
Operating Force
30 to 50 g typical
Maximum Operating Frequency
50 to 100 Hz typical
