Excitation
5 to 10 VDC recommended, 12 VDC or VAC max.
Output
2 to 4 mV/V, nominal, depending on model
Accuracy
Standard configurations meet existing ASTM E1820 requirements for accuracy. A test certificate is included. Rod lengths >250 mm (10″) can affect the final class rating.
Linearity
≤0.15% of full scale measuring range, depending on model
Temperature Range
Standard (-ST) is to 1200 °C (2200 °F), optional (-HT) 1600 °C (2900 °F)
Cable
Integral, ultra-flexible cable, 2.5 m (8 ft) standard
Coolant Interface
Two barbed hose fittings for 1/8” (3.2 mm) ID coolant hoses
Operating Force
30 g typical
