Measuring Range
±0.5 mm or ±0.020 inches
Excitation
5 to 10 VDC recommended, 12 VDC or VAC max.
Output
2 to 4 mV/V, nominal, depending on model
Linearity
≤0.20% of full scale measuring range, depending on model
Temperature Range
Standard (-ST) is -40 °C to +100 °C (-40 °F to 210°F)
Cable
Integral, ultra-flexible Teflon® cable, 2.5 m (8 ft) standard
Operating Force
<30 g typical
