Excitation

5 to 10 VDC recommended, 12 VDC or VAC max.

Output

2 to 4 mV/V, nominal, depending on model

Accuracy

Standard configurations meet ASTM E83 class B-1 accuracy requirements for gauge lengths ≥20 mm and class B-2 for <20 mm. All standard configurations meet ISO 9513 class 0,5. A test certificate is included.

Linearity

≤0.15% of full scale measuring range

Temperature Range

Standard (-ST) is -40 °C to +100 °C (-40 °F to 210 °F)

Cable

Integral, ultra-flexible cable, 2.5 m (8 ft) standard

Operating Force

Depends on model configuration; 10 to 100 g typical
