Excitation
5 to 10 VDC recommended, 12 VDC or VAC max.
Output
2 to 4 mV/V, nominal; select at time of order
Accuracy
±1 mm (±0.040 inches)
Resolution
0.2 mm (0.008 inches)
Temperature Range
-40 °C to 100 °C (-40 °F to 210 °F)
Cable
Integral, ultra-flexible cable, 2.5 m (8 ft) standard
Operating Force
<200 grams typical per head
