Excitation

5 to 10 VDC recommended, 12 VDC or VAC max.

Output

2 to 4 mV/V, nominal, depending on model

Accuracy

All standard configurations meet ASTM E1820, ISO 12135, and ISO 9513 Class 1 requirements for accuracy. A test certificate is included. Models that additionally meet ASTM E399 accuracy requirements are available in 2.5 and 4.0 mm (0.10 and 0.15 inch) meas

Linearity

≤0.2% of full scale measuring range

Temperature Range

Standard (-ST) is -40 °C to +100 °C (-40 °F to +210°F)

Cable

Integral, ultra-flexible cable, 2.5 m (8 ft) standard

Operating Force

9 to 14 N (2 to 3 lbs), depending on model
