Analog Output
User specified, ±10V typical, ±10.8V rail
Digital Output
24 bit high speed Ethernet output with built-in web interface
Accuracy
All standard configurations meet ASTM E1820, ISO 12135, ISO 9513 Class 0.5, and ASTM E399 (up to 3mm) requirements for accuracy
Linearity
11 point linearization, ≤0.15% FS typical linearity
Resolution
<55 PPM (0.006%FS) RMS @ 4 kHz, <6 PPM (0.0006%FS) @ 100 Hz
Temperature Range
Ambient to 700 °C (1300 °F). Use up to 800 °C is possible – contact Epsilon for details. Springs may require periodic adjustment or replacement after long-term testing above ~600 °C.
Temperature Sensitivity (Gain)
<100 PPM / °C (0.01%FS/°C) typical
Output Cable
Flexible 2.4 m (8 ft) analog output cable
Operating Force
10-50 N typical, depending on model
Environment
Recommended for elevated temperature testing in dry air or inert / non-corrosive gases
