Measurement Range
8 to 127 mm (0.3 to 5 inches)
Max. Resolution
0.001 mm (0.0001 inches)
Max. Scan Rate
100 scans/second
Linearity
±0.01 mm (±0.0004 inches)
Repeatability
±0.005 mm (±0.0002 inches)
Analog Output
16 bit, ±10 VDC standard
Power Input
115 VAC ±10%, 50/60 Hz standard 230 VAC ±10%, 50/60 Hz optional
Size
381 L x 180 H x 114 W mm (15 L x 7.1 H x 4.5 W inches)
